Scale plan view of a conventional US painted bike lane, showing how much of the marked lane falls inside the reach of an opening car door.
Dimensions: 8 ft parking lane, 5 ft bike lane (AASHTO minimum), 11 ft travel lane; parked car 6 ft wide set 6 in from the curb; door reach 3½ ft. The bicycle is a front-loading cargo bike, drawn to Riese & Müller Load 75 proportions.
Supersedes File:Painted bike lane door zone geometry.png, which can be deleted.
Drawn for User:JMyles/Why Car Lanes Divide Us.
